swim spa program step-by-step



Meet your personal swim coach!




swim mode

(only available if the swim option is activated in the spa configuration)









Swim Settings

step 1

To access your swim spa training drills, touch the swimmer icon on the left.

Before choosing one, we recommend to adjust the parameters. Touch the settings icon on the right icon wheel.

From there, you can access 5 different parameters.

step 2

The first one is Warm up. There, you can adjust the duration and intensity of your training warm-up by touching the up and down arrows.

Once done, touch the settings icon to go back to the main settings menu.

step 3

The second one is Cooldown. There, you can adjustthe duration and intensity of your training cooldownby touching the up and down arrows.



step 4

Adjust the training drill Step Time durationby touching the up and down arrows.

step 5

Preparation Time gives you some time to get into swimming position after touching the start buttonand before the pumps actually start. You can setthe duration of your preparation time by touchingthe up and down arrows.

step 6

Finally, the light option gives you the possibilityto select which in.mix zones you want to use foryour swim feedback (requires an installed in.mix).







Training Drills - Endurance

step 1

To select a training drill, touch the training drill iconon the top of the right wheel icon.

If you choose Endurance the swimming workoutwill be executed at a constant intensityfor the entire set duration.

step 2

You can adjust the duration and intensity of yourEndurance training drill by touchingthe up and down arrows.

Touch Start when ready.

step 3

The preparation countdown is displayed, allowing you to get in position before your swimming session starts. Your in.mix controlled lights will blink duringthe countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touchingthe sleep icon located at the top right of the screen.It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 4

During the workout session, you can follow your progression with the swimmer icon moving towardright over the training duration bar.

You can touch Pause or Stop whenever you need.

step 5

Touch Pause to suspend your swim session. You will be able to change the intensity level of your drill or go in other menus to start the music, for example.

Touch Resume when ready to swim again.The workout session will resume but the preparation countdown stopwatch won’t reappear.

step 6

If you touch Stop to interrupt your swim session,you will be able to change the duration and/orthe intensity of your session, select another training drill or modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start.







Training Drills - Lap

step 1

To select a training drill, touch the training drill iconon the top of the right wheel icon.

If you choose Lap, this training drill will perform highand low intensity intervals of equal step time.

step 2

You can adjust the duration and intensity of your Lap training drill by touching the up and down arrows.

Touch Start when ready.

step 3

The preparation countdown is displayed, allowing you to get in position before your swimming session starts. Your in.mix controlled lights will blink duringthe countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touchingthe sleep icon located at the top right of the screen.It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 4

During the workout session, you can follow your progression with the swimmer icon moving toward right over the training duration bar.

Your in.mix controlled lights will change colors before each interval to inform you of the change of intensity(requires an installed in.mix).

You can touch Pause or Stop whenever you need.

step 5

Touch Pause to suspend your swim session. You will be able to change the intensity level of your drill or go in other menus to start the music, for example.

Touch Resume when ready to swim again.The workout session will resume but the preparation countdown stopwatch won’t reappear.

step 6

If you touch Stop to interrupt your swim session,you will be able to change the duration and/or the intensity of your session, select another training drillor modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start..







Training Drills - Transition

step 1

To select a training drill, touch the training drill iconon the top of the right wheel icon.

If you choose Transition, this training drill will performa series of equal steps at random intensities.

step 2

You can adjust the duration and intensity of your Transition training drill by touchingthe up and down arrows.

Touch Start when ready.

step 3

The preparation countdown is displayed, allowing you to get in position before your swimming session starts. Your in.mix controlled lights will blink duringthe countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touchingthe sleep icon located at the top right of the screen.It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 4

During the workout session, you can follow your progression with the swimmer icon moving toward right over the training duration bar.

Your in.mix controlled lights will change colors before each interval to inform you of the change of intensity(requires an installed in.mix).

You can touch Pause or Stop whenever you need.

step 5

Touch Pause to suspend your swim session. You will be able to change the intensity level of your drill or go in other menus to start the music, for example.

Touch Resume when ready to swim again.The workout session will resume but the preparation countdown stopwatch won’t reappear.

step 6

If you touch Stop to interrupt your swim session,you will be able to change the duration and/or the intensity of your session, select another training drillor modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start.







Training Drills - Cardio

step 1

To select a training drill, touch the training drill iconon the top of the right wheel icon.

If you choose Cardio, this training drill will performtwo successive steps at high intensity for one stepat low intensity.

step 2

You can adjust the duration and intensity of your Cardio training drill by touchingthe up and down arrows.

Touch Start when ready.

step 3

The preparation countdown is displayed, allowing you to get in position before your swimming session starts. Your in.mix controlled lights will blink duringthe countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touching the sleep icon located at the top right of the screen. It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 4

During the workout session, you can follow your progression with the swimmer icon moving toward right over the training duration bar.

Your in.mix controlled lights will change colors before each interval to inform you of the change of intensity(requires an installed in.mix).

You can touch Pause or Stop whenever you need.

step 5

Touch Pause to suspend your swim session. You will be able to change the intensity level of your drill or go in other menus to start the music, for example.

Touch Resume when ready to swim again.The workout session will resume but the preparation countdown stopwatch won’t reappear.

step 6

If you touch Stop to interrupt your swim session,you will be able to change the duration and/or the intensity of your session, select another training drillor modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start.







Training Drills - Power

step 1

To select a training drill, touch the training drill iconon the top of the right wheel icon.

If you choose Power, this training drill will perform a pyramid program where the intensity will progressively increase until a maximum intensity level is reached. It will then decrease progressively to end at low intensity.

step 2

You can adjust the duration and intensity of your Power training drill by touchingthe up and down arrows.

Touch Start when ready.

step 3

The preparation countdown is displayed, allowing you to get in position before your swimming session starts. Your in.mix controlled lights will blink during the countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touchingthe sleep icon located at the top right of the screen.It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 4

During the workout session, you can follow your progression with the swimmer icon moving toward right over the training duration bar.

Your in.mix controlled lights will change colors before each interval to inform you of the change of intensity(requires an installed in.mix).

You can touch Pause or Stop whenever you need.

step 5

Touch Pause to suspend your swim session. You will be able to change the intensity level of your drill or go in other menus to start the music, for example.

Touch Resume when ready to swim again.The workout session will resume but the preparation countdown stopwatch won’t reappear.

step 6

If you touch Stop to interrupt your swim session,you will be able to change the duration and/or the intensity of your session, select another training drillor modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start.







Training Drills - Personalized

step 1

Three personalized training drills are available and canbe edited to create custom workouts.

Touch the pencil icon at the right end of the desired personalized drill to open the training drill edit window.

step 2

Draw with your finger the desired workout patternon the screen.

Name your personalized training by touching the pencil icon located at the right of the workout name.

step 3

Type your workout name. Once done, touch the returnkey to get back to the training drill screen.



step 4

Touch Confirm to save your personalized workout.If you cancel, the modifications will not be saved.

step 5

This page allows you to adjust the duration of yourpersonalized training drill by touchingthe up and down arrows.

Touch Start when ready.

step 6

The preparation countdown is displayed, allowing youto get in position before your swimming session starts.Your in.mix controlled lights will blink during the countdown (requires an installed in.mix).

The keypad can be put in sleep mode by touchingthe sleep icon located at the top right of the screen.It will prevent interruptions of your swim sessionfrom water splashing on the keypad display.

You can touch Pause or Stop whenever you need.



step 7

During the workout session, you can follow your progression with the swimmer icon moving toward right over the training duration bar.

Your in.mix controlled lights will change colors before each interval to inform you of the change of intensity(requires an installed in.mix).

You can touch Pause or Stop whenever you need.

step 8

Touch Pause to suspend your swim session.

Touch Resume when ready to swim again.The workout session will resume but the preparationcountdown stopwatch won’t reappear.

step 9

If you touch Stop to interrupt your swim session,you will be able to change the duration and/or the intensity of your session, select another training drillor modify any other parameters.

Touch Start to start your workout from the beginning.The preparation countdown will start.
