Find all Gecko Alliance's keypad on one website.  Every info, settings, specs and more that you may need


in.k600 overview





Gecko's series of in.k600 keypads offers spa manufacturers a wide range of possible configurations, making our in.xm platform a perfect solution for mid-range to high-end and AV equipped spas.


in.k600 keypad by Gecko Alliance

advanced full-function keypad
The in.k600 keypad offers a low profile configuration and enhanced durability. In.k600 can be customized with exclusive enclosure shapes.

with menu-driven interface
Creating a unique experience directly from your spa side, the in.k600 allows control of all functions and programming of the spa system and peripheral accessories.

 or streamlined interface
Built with a great design, the in.k600 features a large LCD display, a streamlined interface and raised keys for an easy control of all in.xm functions.



in.k600 works with X and Y Gecko control systems







streamlined interface in.k600 full-function keypad

With its low profile and a large LCD display, our streamlined interface keypad allows an easy control of all in.xm™ functions and programming, creating a true and unique experience directly from spa side.
(for in.xm, in.xe, in.yt and in.ye control systems)






streamlined interface notification icons


light icon

light icon is activated when the light is on


pumps icons

pumps indicators light up according to their speed


blower

blower icon is animated when the blower is on


service icon

do not enter water! spa service  required


smart winter

SWM icon turns on when freeze protection is active and blinks when performing a freeze protection purge


economy mode

economy mode icon lights up when filter cycle is on



filter cycle

filter icon lights up when filtering cycle is activated


heater icon

heater icon lights up when the heater is in function


progress bar

time remaining before an equipment is turned off or before end of standby mode


set point icon

turns on when set point setting menu is activated


program icon

program icon lights up when programming







menu-driven interface in.k600 full-function keypad

The menu-driven model controls all functions and programming of the spa system. The user can adjust the settings of peripheral accessories, creating a unique experience directly from the spa side.
(for in.xm control systems only)






menu-driven interface notification icons




light icon

animated when the light is on. Its speed is proportional to the light intensity


pumps icons

light up and icons are fast or slow animated according to their speed


blower

the blower indicator becomes animated when the blower is activated


service icon

 problem has been detected. Do not enter the water! spa service required


smart winter

SWM icon turns on when the smart winter mode is enabled


economy mode

The Economy icon flashes when Economy mode is in function





filter cycle

animated when filtering cycle is on and flashes when it is suspended


waterfalls icon

this icon becomes animated when the spa waterfall is in function


heater

The heater icon becomes animated when the heater is activated


progress bar

time remaining before equipment is turned off or end of standby mode


setpoint icon

turns on when the menu is activated. It fashes when there is a call for heat; if it has just turned off or if system is making a check flow


stanby icon

the Standby icon flashes when the standby mode has been activated



navigation icon

indicates available active keys for navigation between options or screens


Lock icon

when the keypad is locked, the lock icon will be displayed


hourglass icon

this icon is displayed when screen waiting is required






in.k600 keypad specifications

Environmental:

  • Operating temperature: 149°F (65°C) to -68°F (-20°C)
  • Storage temperature: 185°F (85°C) to -22°F (-30°C)
  • Standards: IP ratings IPX-6



in.k600 keypad docs



quick reference cards



quick reference card download of the in.k600 series full-function and multi-feature keypads with menu driven or streamlined interface for in.xm and in.xe





in.k600 with menu-driven interface for in.xm
Read on screen

in.k600 with streamlined interface for in.xm
Read on screen

in.k600 with streamlined interface for in.xe
Read on screen

in.k600 menu-driven qrc for in.xm:

in.k600 streamlined qrc for in.xm:

K600 streamlined qrc for in.xe:









techbooks



techbooks download of full-function and multi-feature keypads with menu driven or streamlined interface

in.k600 with menu driven interface techbook
Read on screen

in.k600 with streamlined interface techbook
Read on screen

k600 menu-driven techbook:

k600 streamlined techbook:
